Detection Capabilities:
Opening Detection: Utilizes a reed switch and magnet to detect door or window openings.
Shock Detection: Built-in accelerometer senses impacts or vibrations indicating forced entry attempts.
Tilt Detection: Detects changes in vertical angle exceeding 5°, useful for monitoring objects like skylights or tilted windows.
External Detector Integration:
Wired Input: Supports connection of third-party detectors with Normally Closed (NC) contacts, such as motion or roller shutter detectors.
Configurable Settings: Allows customization of alarm triggers based on the connected device's characteristics.
Communication:
Protocol: Jeweller two-way radio protocol ensures secure and reliable communication with Ajax hubs.
Range: Up to 1,200 meters in open space.
Encryption: Features block encryption with a dynamic key for enhanced security.
Power Supply:
Battery: Powered by a CR123A battery (3V).
Battery Life: Up to 5 years under normal usage conditions.
Installation and Configuration:
Mounting: Designed for indoor installation using the included SmartBracket.
Setup: Easily configured via the Ajax mobile or desktop applications.
Tamper Protection: Equipped with a tamper button to detect unauthorized removal or tampering.
Physical Characteristics:
Dimensions: 20 × 90 mm.
Weight: 29 g.
Color Options: Available in white and black.
Operating Conditions:
Temperature Range: 0°C to +49°C (32°F to 120°F).
Humidity: Up to 75%.
Protection Class: IP50.
ajax.systems
Additional Features:
Always Active Mode: Option to keep the detector active regardless of the system's armed status.
Chime Function: Can emit a sound when the door is opened while the system is disarmed.
Event Logging: All events are logged and can be reviewed in the Ajax applications.
